The Clarius® Plus range of high performance Infra-Red LED illuminators are designed to provide class leading performance, long life and ultra low maintenance.
Incorporating the latest surface mount Dual core LED’s with enhancedoptical output and outstanding reliability, they deliver excellent night-time images.
Each unit is fitted with integrated control circuitry to carefully control LED output, delivering consistent illumination and projected working life in excess of 10 years.
The Clarius® Plus range of illuminators includes a new interchangeable lens diffuser system; which allows the user to quickly and easily alter the angle of illumination. Elliptical beam profiles allow more light to be delivered where it is needed, allowing both longer distances and minimising light wastage. The system also helps to prevent overexposure of foreground objects.
- Small IR Illuminator
- Latest SMT Dual Core LED™ Technology
- Distances Up To 132m (434’)
- Angle 10º, 20º, 30º, 60º, 80º & 95º
- Elliptical Beam Profiles
- 850nm Wavelengths
- Low Power Consumption (15W)
- Long Life
- IP66 Weather Proof Rating
- Built-in Photocell IR On/Off
- Photocell Following Contact
- Telemetry Input for Remote Switching
- 12-32V DC / 24V AC +/-10%
- CleanLITE® Self Cleaning Lens Coating Technology
